HP Latex 115 Print & Cut Printer (54 inch/1.37m)

The HP Latex 115 Print and Cut Solution is an easy, affordable printer, cutter and software solution that produces up to 54-inch/1.37m addressable width prints with unrivalled versatility and healthier printing with water based HP Latex Inks. The HP Latex 115 Print and Cut Solution is ideal for entry to outdoor and indoor signage and prints, perfect for small spaces or single operator shops, and an environmentally-minded solution to replace solvent-based technology. The HP Latex 115 Print and Cut Solution features automatic, fast, reliable low-maintenance printing on a wide range of media from vinyl, textiles, paper, film, wall paper to low-cost uncoated options.

With 100’s of media available, expand your services to the growing temporary textiles, vehicle graphics, and wall covering markets and produce great results whether printing point of purchase posters, outdoor and event banners, vehicle wraps and graphics, backlit applications, wall coverings and canvas.

At Design Supply, an HP Gold Partner and DesignJet Graphics Specialist, we work closely with HP to provide the best solutions available to get the job done for your business and maximize your opportunities. With over 27 years of experience in the large format printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.

SKU: 1LH39A Category: Tag:

Description

The HP Latex 115 Print and Cut Solution is an easy, affordable printer, cutter and software solution that produces up to 54-inch/1.37m addressable width prints with unrivalled versatility and healthier printing with water based HP Latex Inks. The HP Latex 115 Print and Cut Solution is ideal for entry to outdoor and indoor signage and prints, perfect for small spaces or single operator shops, and an environmentally-minded solution to replace solvent-based technology. The HP Latex 115 Print and Cut Solution features automatic, fast, reliable low-maintenance printing on a wide range of media from vinyl, textiles, paper, film, wall paper to low-cost uncoated options.

With 100’s of media available, expand your services to the growing temporary textiles, vehicle graphics, and wall covering markets and produce great results whether printing point of purchase posters, outdoor and event banners, vehicle wraps and graphics, backlit applications, wall coverings and canvas.

At Design Supply, an HP Authorised Partner and DesignJet Specialist, we work closely with HP to provide the best solutions available to get the job done for your business and maximise your opportunities. With over 28 years of experience in the large format printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.



VIDEOS

HP Latex Print and Cut Solutions:115,315,335

HP Latex 115 Large Format Printer

HP Latex Print and Cut

HP Wall Art

HP Latex Canvas Possibilities

How to mount a Canvas

Ontario Museum

Unique Frescos restored

HP Latex: Wallpaper company



KEY FEATURES

Print more applications, full bleed stickers (without shrinkage or curling) and reach indoor spaces that solvent solutions can’t with the new HP Latex 115 Print and Cut Solution. Best in class based on productivity and environmental advantages compared to the leading and comparably priced solvent-technology based integrated print and cut solutions, HP Latex 115 Print and Cut Solution features LAN connectivity, optimised workflow management from a single point and includes software with barcode integration.

The HP Latex 115 Print and Cut Solution features an integrated workflow with HP Signage Suite and HP FlexiPrint and Cut RIP software. Use HP Signage Suite to design applications in three simple steps, then HP FlexiPrint and Cut RIP to simultaneously print and cut. Add cut lines automatically from the RIP, define job settings easily, and use barcode integration. HP Latex 115 prints are completely cured and dry inside printer, ready for immediate finishing, making the HP Latex 115 Print and Cut Solution a true print and cut, reliable dual-device solution. Enjoy all the befits of HP Latex printing technology, including scratch resistant prints, ideal for short term applications (and avoiding lamination) saving time and money. High quality prints at high printing speeds, means jobs can be delivered in the same day.

The HP Latex Cutter works as one with the HP Latex 115 Printer, delivering reliable, efficient job recognition and error-free cutting using the Optical Positioning System (OPOS) and HP Barcode. Print and cut in five simple steps, by adding cut lines from the RIP, predefining cutting presets with the easy user interface.

SPECIFICATIONS

HP Latex 115 Printer produces up to 1200 x 1200 dpi resolution with HP double swath technology and has a maximum print speed of 48m2/hr. The following are print speeds based on user-selected print modes and four or 6 colours.

Print Mode (bidirectional) Viewing distance m2/hr ft2/hr
Billboard (2-pass, 4c) >5m 48 517
Outdoor Plus (6-pass, 6c) >3m 16 174
Indoor Quality (8-pass, 6c) 1-3m 12 129
Indoor High Quality (10-pass, 6c) <1m 10 108
Backlits, Textiles, Canvases (16-pass, 6c) <1m 6 65
High Saturation Textiles (20-pass, 6c) <1m 5 54

The HP Latex 115 Printer includes the HP Latex Optimizer, which interacts with HP Latex Inks to rapidly immobilize pigments on the surface of the print and achieves high image quality at high productivity. HP Latex 115 Printer features a colour sensor densitometer for colour management, enabling automatic calibration for paper-based media (but not for textiles and banners). HP Quick Substrate Profiling includes a full set of onboard generic and specific HP substrate profiles and access to an online substrate profile library of over 250 custom profiles and the ability to fine tune, edit, clone and remove profiles. HP 821 Latex Ink cartridges are available in 400 ml and HP Latex printheads feature 1200 nozzles per inch, and are user-replaceable, maintaining image quality over the life of the printer.

The HP Latex Cutter includes a drag-knife with Turbo-Cut and Tangential emulation modes. The cut width is 135 cm (53.1 inch) and the cut thickness is 0.05 to 0.25mm (0.002 to 0.01 inch). An optional sandblast blade increases the cut thickness up to 0.8mm (0.03 inch). The cut speeds are up to 84 cm/sec (33 in/sec), diagonal 113 cm/sec (44 in/sec), for media narrower than 737 mm (29 in).

The HP 54-inch Take Up Reel is an optional accessory and productivity booster for unattended printing. The 54-inch single spindles handle up to 25 kg (55 lb.) and multiple spindles are available for quick ready to load multiple media versatility and convenience.

HP Wall Art is free, cloud-based software designed to use with HP Latex Printers. Voted in 2013, the “Best Special Application Solution” by the European Digital Press Awards. HP Wall Art features design, 3D visualization, job sharing, automatic PDF printing files, creation of customised installation instructions and developers kit to allow integration into websites.

There are 100’s of different media for the HP Latex 115 Series printers, including a broad choice among coated or uncoated, vinyl, paper, PVC-free wallpaper, banner (light display, heavy); fabrics (cotton, eco-cotton, polyester, heat-sensitive polyesters, synthetic leather, silk) canvas and many more. Choose from a wide range of compatible substrates from industry-leading media providers including specialty substrates, deep embossed, textured or metallic coated media. Our media specialists at Design Supply have the expertise to help you determine the best solutions for your particular printing needs. HP Latex prints feature a flexible ink layer, ideal for conforming to complex surfaces, including vehicle wraps and canvas (everyday satin, premium satin, gesso coated, inkjet coated, gallery wrap). For more information, including the 3M MCS Warranty, ask your Design Supply account manager.

Count on dependable support to create the best image possible from HP and Design Supply. For added peace of mind, HP Latex 115 Print and Cut Solution feature a 12-month limited hardware warranty. HP Services offer a broad portfolio of proven support programs to help keep your business running productively including HP Care Pack Services, an extensive portfolio of installation and post warranty on-site support services and preventative maintenance kits and HP Ecosolutions Training for printing companies to help enhance printing and imaging environments and protect your investment and grow your business. Ask us at Design Supply, and we can tailor the best solution possible for your needs.

WHAT'S IN THE BOX

HP Latex 115 Print and Cut Solution

HP Latex 115 Printer: 1LH39A

HP 831 Latex Printheads (6): CZ677A, CZ678A, CZ679A, CZ680A

HP 831 Maintenance cartridge: CZ681A

Printer stand

2-in Spindle with 3-in core: FOM55A

HP Latex maintenance kit : FOM59A

HP Latex Edge holders: FOM64A

Quick reference guide

Setup poster

Power Cords

One year provided that the HP Latex End of Installation Registration is completed by an HP authorised reseller.

HP Latex 54 Basic Cutter:

Cutter stand

Media basket

HP FlexiPrint and Cut RIP

HP Cutter Control software

Quick reference guide

Setup poster

Documentation software

Power cords

Standard holder (1)

Standard blades (2)

Cut-off knife (1)

3-in media flanges (set of 2)

One year provided that the HP Latex End of Installation Registration is completed by an HP authorised reseller.

Accessories:

HP Latex Cutter Extended Kit: 1UP26A

HP Latex 2-in Media Holder Kit: 1UP27A

HP Latex Standard Blade Kit: 1UX44A

HP Latex Specialty Blade Kit: 1UX45A

HP Latex User Maintenance Kit: F0M59A

HP Latex Edge Holders: FOM64A

HP Latex 54-in Printer 2-in Spindle: FOM55A

HP Latex 54-in Take Up Reel: W5A60A

Consumables:

HP 831 Cyan/Black Latex Printhead: CZ677A

HP 831 Yellow/Magenta Latex Printhead: CZ678A

HP 831 Light Magenta/Light Cyan Latex Printhead: CZ679A

HP 831 Latex Optimizer Printhead: CZ680A

HP 821 400ml Black Latex Ink Cartridge: GOY89A

HP 821 400ml Cyan Latex Ink Cartridge: GOY86A

HP 821 400ml Magenta Latex Ink Cartridge: GOY87A

HP 821 400ml Yellow Latex Ink Cartridge: GOY88A

HP 821 400ml Light Cyan Latex Ink Cartridge: GOY90A

HP 821 400ml Light Magenta Latex Ink Cartridge: GOY91A

HP 821 400ml Latex Optimizer Ink Cartridge: GOY92A

HP 831 Latex Maintenance Cartridge: CZ681A

Media:

HP PVC-free Wall Paper (FSC and UL GREENGUARD GOLD Certified)

HP Permanent Gloss Adhesive Vinyl (REACH Compliant)

HP Backlit Polyester Film

HP Premium Satin Canvas

For a complete list, please speak to your Design Supply account manager

For more information on the 3M MCS Warranty for Certified Graphics Manufacturers, please speak to your Design Supply account manager

Service and support:

HP 3 Year Next Business Day Defective Media Retention: U9TS4E

HP 2 Year Next Business Day Defective Media Retention: U9TS3E

HP 2 Year Post warranty Next Business Day Defective Media Retention: U9TS8PE

HP 1 Year Post Warranty Next Business Day Defective Media Retention: U9TS7PE

DATA SHEETS

HP Latex 115 Print and Cut datasheet

HP Latex 115 Printer datasheet

HP Latex 115 315 335 portfolio datasheet

HP Latex Portfolio comparison datasheet

HP Latex inks and durability brochure

HP Latex Mobile datasheet

HP PrintOS Mobile App datasheet

HP Latex Printing Technology: environmental certifications and eco-labels overview datasheet

HP Graphics Solutions for Photofinishers and Photo Labs brochure

HP Latex Printers and Wall Paper Certifications datasheet

HP Cookbook Durable Textiles brochure

HP Customised Optimisation Services datasheet

HP  JetAdvantage datasheet



MANUFACTURER INFORMATION

HP Latex proprietary technology provides innovation in versatility, flexibility and durability, driving the transformation of the industry and expanding applications to the interior decoration market. Introduced in 2009 as a result of over ten years of research, development, and investment, thousands of HP Latex Ink systems are now employed worldwide and have printed more than 35 million square meters. HP Latex offers the versatility to cover applications including retail and outdoor advertising, event and exhibition graphics, vehicle graphics and interior decoration. The water-based formulation of HP Latex Inks meets high environmental standards that improve the work environment and meet customers’ environmental objectives for indoor displays and wall coverings.

HP Latex proprietary technology makes it possible to obtain high quality at production speeds at no extra cost compared to solvent printing technology. Versatility of media, including coated and uncoated substrates deliver odourless prints and do not require ventilation, moving the industry to healthier printing. The smooth, flexible ink layer is ideal for stretching and framing canvases. User replaceable printheads maintain image quality over the life of the printer. Scalable printhead technology enables a range of products with speeds ideal for low to medium volume printing. Delivery times are shortened; prints come out completely dry, and can be laminated immediately. Maintenance is reduced with HP water-based Latex Inks, which do not require daily manual cleaning and printers can be turned off overnight, on weekends, or longer. The HP Latex 300 Series printers are third generation technology.

HP Latex Ink Cartridges feature built-in electronic intelligence that communicates ink colour, remaining ink quantity and other information for the printer. HP Latex Inks are water-based inks that combine the best characteristics of solvent inks and water-based inks. Water give HP Latex inks the high surface tension, low viscosity and energetic vapour bubble that are ideal for use in thermal HP inkjet printheads. Composed of more than 60% water, HP Latex Inks offer important benefits to commercial and industrial production environments – water produces no VOCs (volatile organic compounds), requires no special handling, and is non-toxic, non-flammable and non-combustible. Humectants, wetting agents and additives are used to obtain required performance characteristics for an ink.

The HP Latex 115 Print & Cut Solution features a print zone, located on the printer platen under the scanning carriage. Here heaters evaporate some of the water, allowing the concentrated humectants and wetting agents to soften the surface of uncoated vinyl for better adhesion of the colourant layer. Remaining liquids in the ink film are evaporated by curing zone dryers to produce a completely dry and odourless print that can be immediately handled, stored, shipped or displayed indoors. The HP Optimizer interacts with HP Latex Inks to rapidly immobilize pigments on the surface of the print and achieve high image quality at high productivity.

Environmental Certifications and Eco Labels Overview:

Since 1992, HP focuses on specific environment impacts through its Design for Environment (DfE) program. DfE is an engineering perspective where the environmentally related characteristics of a product, process, or facility are optimized. Together, HP’s environmental stewards and product designers consider impact on the design of every product and solution, from the smallest ink cartridges to entire data centres. HP Latex Printing Technologies provide many opportunities to reduce and recycle. Below are the certifications for the HP Latex 115 Print and Cut Solutions, HP 821 Latex Ink Cartridges, and selected HP Media.

EL ECOLOGO Certification to UL 2801 demonstrates that HP Latex Inks meet a range of stringent criteria related to human health and environmental conditions. UL GREENGUARD GOLD Certification to UL 2818 means HP Latex products are certified to GREENGUARD standards for low chemical emissions into indoor air during product usage. HP Wall Art printed on HP PVC-free wall paper and other prints on HP PVC-free wall paper printed with HP Latex Inks meet AgBB criteria for health-related evaluation of VOC (volatile organic compounds) emissions of indoor building product. Rated A+ per Émissions dans l’air intérieur refers to the level of emission of volatile substances in indoor air posing health risks if inhaled. Eco Mark Certification Number 14142007 is for the HP 831 Latex Ink Cartridges, certified by the Eco mark Office of Japan Environment Association. Energy Star qualified means the HP Latex 115 Print and Cut Solution meets strict energy efficiency guidelines without sacrificing performance and are EPEAT registered. Additionally, other certifications for some medias/textiles include EN22 standards for wash ability and colourfastness and Euro Class Standard Class B4 for flame retardant and CE Mark Type II (ASTMF793) compliant for durability characteristics.

HP printing materials are designed together with HP Latex Inks and HP Latex printers provide optimal image quality, consistency, and reliability. These include HP PVC-free Wall Paper (FSC and UL GREENGUARD GOLD Certified), HP Permanent Gloss Adhesive Vinyl (REACH compliant), HP Backlit Polyester Film (recyclable), and HP Premium Satin Canvas.
