WideTEK 36CL-600-MF5 Large Format A0 Scanner

WideTEK 36CL-600-MF5 Large Format A0 Scanner - Image 3

WideTEK 36CL-600-MF5 Large Format A0 Scanner - Image 4

WideTEK 36CL-600-MF5 Large Format A0 Scanner - Image 5

WideTEK 36CL-600-MF5 Large Format A0 Scanner - Image 6

WideTEK 36CL-600-MF5 Large Format A0 Scanner - Image 7

The WideTEK 36CL-600-MF5 Large Format Scanner scans, copies and archives documents up to 36 inches/ 914mm at high speed. Designed to sit on top of the Canon TM 300 Printer Series, the WideTEK 36CL-600-MF5 is a fast colour CIS scanner and provides 100% integration and is deal for the Technical & CAD Drawing Office, Construction, Building Services, Facilities Management, Military, Electronic Document Capture and Small Office/Home Office environments.

SKU: WT36CL-600-MF5-1 Category: Large Format Discontinued Tag: No Lease

WideTEK

Description

The WideTEK 36CL-600-MF5 Large Format Scanner scans, copies and archives documents up to 36 inches/ 914mm at high speed.

Designed to sit on top of the Canon TM-300 Printer, the WideTEK 36CL-600-MF5 is the fastest colour CIS scanner on the market and provides 100% integration and is deal for the Technical & CAD Drawing Office, Construction, Building Services, Facilities Management, Military, Electronic Document Capture and Small Office/Home Office environments.

Whether you are an Architect, Engineer, GIS professional, Archivist, Administrator, you can scan engineering drawings, blueprints, architectural renderings, maps, site plans and much more.

Save time and money you will no longer need to send out for scans, as they can be done in house, quickly, and at your own convenience.

At Design Supply, an Authorised WideTEK Reseller and an Accredited Canon Gold Partner, we work closely with WideTEK and Canon to provide the best solutions available to get the job done for your business and maximise your opportunities. With over 28 years of experience in the large format scanner and printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.

VIDEOS

WideTEK 36CL-600-MF5 Large Format Scanner

KEY FEATURES

The WideTEK 36CL-600-MF5 Large Format Scanner scans, copies and archives documents at high speed and together with Canon TM-300 Series printers, creates a powerful and high quality MFP (multi-function printer) system. The WideTEK 36CL-600-MF5 includes a built-in PC, a 21″ touchscreen, all software (pre-installed) and the Canon TM stand, developed specifically for the Canon TM 300 Series printers. Discover the true walk up solution for fast scanning at the optimum resolution required to capture the original image detail without compromising quality with the smallest footprint possible.

The WideTEK 36CL-600-MF5 Large Format Scanner features an integrated 64-bit Linux PC with all the software installed, so the scanner is ready to go, without requiring drivers,additional scanning software, or PC. Installation is simple, once you assign the IP address, you are ready to scan and copy. The large 21″ touchscreen provides simplified operation and ScanWizard and PrintWizard software are easy to use and provide 100 % integration of all scanner and printer features.

Inserting documents into the WideTEK 36CL-600-MF5 Large Format Scanner is fast and easy. Documents go face-up,with a center feed and automatic document positioning and size detection eliminate the need for complicated settings. The durable, anti-static paper path is designed to allow the scanning of many different types of media without requiring any adjustments. Document skewing is virtually eliminated, even when scanning unlimited lengths to multipage PDFs.

The WideTEK 36CL-600-MF5 features LED illumination and true 1200 x 600 dpi optical resolution, providing details of scanned documents not even visible to the human eye. The colour space of WideTEK CIS cameras are much wider than SRGB and WideTEK’s unique online ICC profiling eliminates the last remaining imperfections. The scan generated can be saved in many different formats, including JPEG or PDF, and sent directly to the Canon TM 300 Series printer. Alternatively, the WideTEK 36CL-600-MF5 scans directly to USB, network, cloud, or mobile devices via Scan2PAD.

The WideTEK 36CL-600-MF5 features a built-in closed loop colour calibration at no extra cost, generating the best possible copies for your selected printer and paper combination. ScanWizard provides 100% integration of all printer features: select media type, printing quality and more, and track ink levels all through one application.

The WideTEK 36CL-600-MF5 Large Format Scanner is ideal for boosting productivity. In addition to fast scan speeds, even at high resolution, the WideTEK 36CL-600-MF5 features proprietary Scan2Net technology, a 1GB fast Ethernet with TCP/IP based interface. Fast data transfer means there are fewer communication bottlenecks and you can always scan the largest and longest documents in the greatest detail fast.

SPECIFICATIONS

The WideTEK 36CL-600-MF5 scanner is a true stand-alone device with the smallest footprint, OS independent, and runs with Windows 7, 8, 10, Linux and Mac. The inbuilt PC is a 64 bit Linux operating system with a real time processing kernel. The inbuilt PC features an Intel dual quad core, 1.8 – 3GHz processor, a built in graphics engine, x-Windows, 128GB SSD, and 8 Gigabyte RAM for very long scans. It features a failsafe file system, factory installed disaster recovery hard disk partition and is fully virus protected.

The WideTEK 36CL-600-MF5 features the Scan2Net platform, running inside the scanner and replaces proprietary scanner drivers and software that traditional scanners require with the fastest common, non-proprietary connection available: TCP/IP over Ethernet. With network interface speeds much higher than USB or SCSI, Scan2Net devices are able to reach unrivaled performance at very low connectivity cost. The Linux based operation system is dedicated to scanner specific imaging and mechanical control tasks, further maximising scanning speeds and performance. Scan2Net is the built-in network interface with 1GB fast Ethernet with TCP/IP. Scan2Net makes connecting the WideTEK 36CL-600-MF5 large format scanner easy. Simply connect power and an Ethernet cable directly to a PC or to your organisation’s network, assign a valid IP address to your WideTEK scanner, start your browser and the built-in ScanWizard, and scan. Scan2Net technology also enables remote maintenance, troubleshooting, and firmware updates via the web interface, as well as output to SMB, FTP, Printer, and email.

ScanWizard is an integrated scan application for use with any browser, including ID, Edge, Safari, Firefox, and Chrome. ScanWizard saves scans to Multipage PDF (PDF/A) & TIFF, JPEG, JPEG 2000, PNM, PNG, BMP, TIFF (Raw, G3, G4, LZW, JPEG) AutoCAD DWF, JBIG, DjVu, DICOM, PCX, PostScript, EPS, and raw data. Scans can also be directly output to the integrated USB port located on the front of the WideTEK 36CL-600 MF5. ScanWizard offers an extensive set of scanning tools and image treatment functions and is a Java script application which runs on any browser. With the same look and feel on all platforms, ScanWizard runs like a desktop program, and is simple to use. An intuitive menu leads the user quickly to the desired feature or function. Select document size, file format, image orientation, output mode, colour mode, press the start button and scan. If the settings are exactly what the user wanted, changes can be made on the fly without the need to rescan the document. ScanWizard display the scanned image on the 21″ Touch screen, and a built-in magnifier is available look closely at every detail of the scan. ScanWizard enables mixed batches of scanning and stores them in multipage PDF-A files or other formats. ScanWizard supports multiple users, multiple jobs and tasks and supports multiple languages.

PrintWizard converts every WideTEK scanner to a powerful multi function scan and print solution and is an extension to the ScanWizard. PrintWizard adds print and copy functionality including full control of all features of the attached printer, even paper properties of levels of available ink without having to physically access the printer.

ScanWizard and PrintWizard each have five predefined scanner and printer templates for ease of use, and new customised templates can be added. The copy button is freely configurable and allows a single button copy function, using any one of the templates, simplifying the task of making copies of a large set of documents.

Scan2Pad, which enables scanning to be controlled and operated using an iPad, an Android tablet, a smartphone (running Android version 3.2 or higher), or an iPhone. Scan2Pad can be used to process scan jobs offline and/or avoid the cloud, with complete scanner control via the mobile device. Print quality copies of scans wirelessly or mail directly from the App. Scan2Pad is available free of charge at the iTunes store. The Android version of Scan2Pad is available free of charge at the Google Play Store.

The large, edge to edge, 21 inch touchscreen with arm is mounted to the WideTEK 36CL-600-MF5 large format scanner and enables direct operation without an external PC. Ideally suited for effective post-scan image previewing, the 21″ Touch monitor features 16:9 full HD (1920 x 1080) resolution, a 3,000:1 high contrast ratio, a wide (178º/178º) viewing angle, sound feedback, and intuitive touch controls for most of the scanner’s functionality via ScanWizard and PrintWizard included with Scan2Net firmware.

The WideTEK 36CL-600-MF5 large format scanner has an integrated stand for mounting on top of the Canon TM 300 Series printer, delivering the smallest footprint for a multi function scan and print solution. For convenience, a USB port for data storage is located on the front of the scanner.

The WideTEK 36CL-600-MF5 Large Format Scanner features an optical resolution of 1200 x 1200dpi and scans up to 36 inches/915 mm with a maximum media width up to 38 inches/965 mm. The WideTEK 36CL-600-MF5 Large Format Scanner accepts media up to 0.1 inches (2.5mm) thick. . The WideTEK 36CL-600-MF5 Large Format Scanner has a colour depth of 48-bit colour, and 16-bit grayscale and has a scan output of 24-bit colour, 8-bit grayscale, bitonal and enhanced halftone.

The WideTEK 36CL-600-MF5 scans 10 inches/25.4 cm per second at 200 dpi in full colour. At the full width of 36 inches/915 mm and at 600 dpi, the WideTEK 36CL-600-MF5 cans at 1.7 inches/4.3 cm per second.

Resolution	Colour (24-bit)	B&W (8-bit grayscale)
200 dpi	10 inches/sec 15 m/min	15 inches/sec 22.9 m/min
300 dpi	6.7 inches/sec 10.2 m/min	15 inches/sec 22.9 m/min
600 dpi	1.7 inches/sec 2.5 m/min	5 inches/sec 8 m/min
1200 dpi	0.8 inches/sec 1.2 m/min	2.5 inches/sec 3.8 m/min

The WideTEK 36CL-600-MF5 features 3 x Canon CIS modules, for a total of 22,389 pixels. The instant-on, bi-directional RGB LED illumination is encapsulated, and dust-proof. The durable, anti-static stainless steel and glass paper path enable face up scanning with rear of front exit . The paper path has a unique 4-wheel drive system for the most gentle paper transport possible. The WideTEK 36CL-600-MF5 is a center feed with automatic size and position detection and also supports right side feed with a guide, enable fast, fiddle-free scanning. Additionally, there are configurable scan templates and target templates for convenience. The absence of plastic parts eliminates static electricity and early wear and tear, and makes cleaning as simple as possible.

WideTEK 36CL-600-MF5 Large Format Scanner features virtual rescan technology, allowing the modification of images without rescanning. All scan parameters including automatic crop and deskew, can be changed on the fly, and the results appear instantly on the 21″ touch preview screen attached directly to the scanner.

The WideTEK 36CL-600-MF5 supports colour management workflows and can capture a colour gamut that far exceeds the sRGB colour spaces, used as an industry recognised standard. ICC profiles are embedded for SRGB, Adobe RBD and native and exceeds FADGI guidelines and meet ISO 19264-1 standards. Individual profiling is available via a web-based Scan2ICC subscription.

Optional accessories for the WideTEK 36CL-600-MF5 large format scanner include an elevated Stand Alone Floor Stand with Catch Basket. Optional software includes Scan2OCR, Scan2ICC, and Scan2Pad. Scan2OCR provides background text recognition during the scan job, Scan2ICC is a web-based subscription for ICC colour management and profiles, and Scan2Pad enables operation via a tablet, smart phone or other mobile device. Extended 9600 x 9600 dpi is also available. An extended full coverage warranty is also available, for added peace of mind. Additional software and hardware options allow the WideTEK scanner to operate with next generation Canon and other manufacturers’ printers including PrintWizard software for Canon TDS Colorwave, PrintWizard for HP PageWide and DesignJet and PrintWizard for Epson SureColor .

As you would expect from WideTEK, reliable performance is a given. Count on dependable support to scan, copy, archive, and print the best image possible from WideTEK and Design Supply. Ask us at Design Supply, and we can tailor the best solution possible for your needs.

WHAT'S IN THE BOX

WideTEK 36CL-600-MF5 Large Format Scanner for Canon TM-300 Series with integrated 64bit Linux PC:WT36CL-600-MF5

TM-300 Mount Kit: WT36CL-TM-MFP-STAND

21″ Touch Screen: WT-TOUCH21

Paper Guide Return: WT36-ET1-03-A

Calibration Targets

Manuals

Software Pre-installed:

ScanWizard:

PrintWizard LFP: WTXX-PW-LFP

Closed loop calibration software

Options:

PrintWizard for Canon TDS Colorwave: WTXX-PW-TDS

PrintWizard for HP PageWide and DesignJet: WTXX-PW-HP

PrintWizard for Epson SureColor: WTXX-PX-EPS

Elevated Floor Stand: WT36-STAND

Scan2OCR- background text recognition during the scan job

Scan2ICC – web-based subscription for idividual profiling of ICC colour management and profiles

Scan2PAD – for operation via tablet, smart phone, and other mobile devices, available free of charge at iTunes or Google Play Stores

Extended 9600 x 9600 dpi interpolated resolution

Warranty options:

Full coverage warranty for 12 months: WTCL-SP12M

Extended coverage warranty for up to 5 years:

DATA SHEETS

WideTEK 36CL-600-MF5 Large Format Scanner

Scan2Net Technology

WideTEK 21″ Full HD Touch Screen

WideTEK Stands and Monitor holders

Unpacking and Repacking Instructions WT36CL-48CL-60CL-600

Assembly instructions for WideTEK WT36CL TM MFP STAND

MANUFACTURER INFORMATION

Image Access is a German-based pioneer of large format scanning and a leading innovator in wide format scanners (WideTEK), book scanners (Bookeye) and production software. Thomas Ingendoh, CEO and founder of Image Access, started the business in February 1994 from the ground up, with a vision of producing the best camera optics on the market. In the 25 years since, Image Access has become the technology leader in large format scanning. Always focused on the core technology of scanners, Image Access grew from a camera manufacturer to today´s large format scanner manufacturer. From its first graphic board with a full colour resolution of 1600 x 1200, developed in 1994 and sold through Siemens Medical; Image Access has emerged to become a highly diversified wide format scanner vendor with the most expansive product offering in the industry — not only sheet feed scanners up to 60″ wide but also book scanners and flatbed scanners in various sizes and a large number of OEM devices. Image Access offers a full range of scanning solutions incorporating first class technological breakthroughs. The WideTEK range include the latest camera technology and built-in closed loop colour calibration, exceeding DADGI guidelines and in ISO 19264-1 level B.

Today, the WideTEK range includes MFP (multi format printing) solutions, fine art, flatbed and sheetfeed CIS and CCD scanners in 12″, 25″, 36″, 44″, 48″ and 60″. Headquartered in Wuppertal, Germany, Image Access also have an office in the USA.
